Yellow 24" Class 300 Ball Valve ISO9001 Bare Stem WCC Trunnion Mounted

1 Set

MOQ

negotiated

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Name: Trunnion Mounted Ball Valve

Material: WCC

Pressure Rating: Class600

Power: Bare Stem ISO 5211

Color: Yellow Or Customer's Request

OEM/ODM: Yes

High Light:

24" Class 300 Ball Valve

Class 300 Ball Valve ISO9001

WCC Ball Valve ISO9001

Basic Infomation

Place of Origin: Sichuan, China

Brand Name: VT

Certification: API 6D, API 607,TS, ISO 9001,TS

Payment & Shipping Terms

Packaging Details: Plywood Case

Payment Terms: L/C, T/T

Supply Ability: 10000 Set Per Year

Gallery

Yellow 24" Class 300 Ball Valve ISO9001 Bare Stem WCC Trunnion Mounted

Product Description

WCB Carbon Steel Trunnion Mounted Ball Valve Flanged 24'' Class 300

Product Description

The Trunnion Mounted ball valve have two valve seats, which can two direction seal.Therefore there is no restriction

on the installation direction, either side of the valve can be used as the upstream side, it is a two-way valve.

Trunnion Mounted Ball Valve Test Procedure

HYDROSTATIC SEAL TEST API 6D 10.3 and 10.4
Sequence	Area Pressure		Duration(min)		Description
SHELL TEST	A	1.5xPN	6″-10″	5	1. Valve in partial open. 2. Set the pressure to 150% PN. 3. Reduce the pressure to 50% PN. 4. Reset the pressure to 150% PN. 5. Hold the pressure for the duration of testing.
	B	1.5xPN	12″-18″	15
	C	1.5xPN	20″-60″	30
SEAT TEST	A	1.1xPN	5		Seat hydrostatic seal at A end towards body B
	B	Atmospheric
	C	Atmospheric
	A	Atmospheric	5		Seat hydro seal at C end towards body B
	B	Atmospheric
	C	1.1xPN
	A	1.1xPN	5		Seat hydro seal test for both A and C
	B	Atmospheric
	C	1.1xPN
AIR SEAL TEST API 6D 10.4
SEAT TEST	A	Atmospheric	5		Seat air seal test at A end towards body B
	B	Atmospheric
	C	80PSLG(5.5bar)
	A	80PSLG(5.5bar)	5		Seat air seal test at C end towards body B
	B	80PSLG(5.5bar)
	C	Atmospheric

24'' 300LB Carbon Steel Trunnion Mounted Ball Valve Details
